03Radio fill animation
Picking a radio grows the inner dot from scale(0) to scale(1), so only the chosen option ever looks filled.
Best forPayment method selection, shipping option picker
scale:checked0.22초

<main class="stage">
<fieldset class="radio-group is-demo">
<legend class="radio-group__legend">Payment method</legend>
<label class="radio"><input type="radio" name="pay" class="sr-input" checked><span class="radio__dot" aria-hidden="true"></span><span>Card</span></label>
<label class="radio"><input type="radio" name="pay" class="sr-input"><span class="radio__dot" aria-hidden="true"></span><span>Bank transfer</span></label>
<label class="radio"><input type="radio" name="pay" class="sr-input"><span class="radio__dot" aria-hidden="true"></span><span>Phone</span></label>
</fieldset>
</main>@use "../../../../site/static/demo-tokens" as *;
// ── 변수 3개 ──────────────────────────────
$duration: $dur-quick;
$easing: $ease-out;
$color: $subject-cream;
// ── 데모 무대 ───────────────────────────────
@include stage($stage-orange);
.sr-input {
position: absolute; width: 1px; height: 1px; padding: 0; margin: -1px;
overflow: hidden; clip: rect(0, 0, 0, 0); white-space: nowrap; border: 0;
}
.sr-only {
position: absolute; width: 1px; height: 1px; padding: 0; margin: -1px;
overflow: hidden; clip: rect(0, 0, 0, 0); white-space: nowrap; border: 0;
}
.radio-group { display: flex; flex-direction: column; gap: clamp(8px, 2.4vw, 12px); border: 0; margin: 0; padding: 0; }
.radio-group__legend {
color: $subject-ink; font-weight: 700; font-size: 12px; line-height: 1; font-family: inherit; letter-spacing: .04em; text-transform: uppercase;
padding: 0 0 2px;
}
.radio { display: inline-flex; align-items: center; gap: 10px; cursor: pointer;
font-weight: 600; font-size: clamp(13px, 3.8vw, 15px); line-height: 1; font-family: inherit; color: $subject-ink; }
.radio__dot { flex: none; width: 22px; height: 22px; border-radius: 50%;
border: 2px solid rgba($subject-cream, .6); display: grid; place-items: center; }
.radio__dot::after {
content: ""; width: 12px; height: 12px; border-radius: 50%; background: $color;
transform: scale(0); transition: transform $duration $easing;
}
.sr-input:checked ~ .radio__dot::after { transform: scale(1); }
.sr-input:focus-visible ~ .radio__dot { box-shadow: 0 0 0 3px rgba($subject-cream, .5); }
@media (prefers-reduced-motion: reduce) {
// 접근성: 움직임 줄이기 설정이면 트랜지션을 즉시 끝낸다
.radio__dot::after { transition-duration: 1ms !important; }
}html, body {
margin: 0;
overflow: hidden;
}
.stage {
box-sizing: border-box;
min-height: 100vh;
display: grid;
place-items: center;
margin: 0;
background: #ff4d1f;
font-family: -apple-system, "Segoe UI", "Noto Sans KR", sans-serif;
padding: clamp(8px, 4vw, 24px);
}
.sr-input {
position: absolute;
width: 1px;
height: 1px;
padding: 0;
margin: -1px;
overflow: hidden;
clip: rect(0, 0, 0, 0);
white-space: nowrap;
border: 0;
}
.sr-only {
position: absolute;
width: 1px;
height: 1px;
padding: 0;
margin: -1px;
overflow: hidden;
clip: rect(0, 0, 0, 0);
white-space: nowrap;
border: 0;
}
.radio-group {
display: flex;
flex-direction: column;
gap: clamp(8px, 2.4vw, 12px);
border: 0;
margin: 0;
padding: 0;
}
.radio-group__legend {
color: #17141a;
font-weight: 700;
font-size: 12px;
line-height: 1;
font-family: inherit;
letter-spacing: 0.04em;
text-transform: uppercase;
padding: 0 0 2px;
}
.radio {
display: inline-flex;
align-items: center;
gap: 10px;
cursor: pointer;
font-weight: 600;
font-size: clamp(13px, 3.8vw, 15px);
line-height: 1;
font-family: inherit;
color: #17141a;
}
.radio__dot {
flex: none;
width: 22px;
height: 22px;
border-radius: 50%;
border: 2px solid rgba(255, 247, 230, 0.6);
display: grid;
place-items: center;
}
.radio__dot::after {
content: "";
width: 12px;
height: 12px;
border-radius: 50%;
background: #fff7e6;
transform: scale(0);
transition: transform 220ms ease-out;
}
.sr-input:checked ~ .radio__dot::after {
transform: scale(1);
}
.sr-input:focus-visible ~ .radio__dot {
box-shadow: 0 0 0 3px rgba(255, 247, 230, 0.5);
}
@media (prefers-reduced-motion: reduce) {
.radio__dot::after {
transition-duration: 1ms !important;
}
}// .is-demo 데모용 자동 순환. 실제로는 클릭이 :checked 를 바꾼다 (6줄)
document.querySelectorAll('.is-demo').forEach(function (grp) {
var inputs = grp.querySelectorAll('.sr-input'); var i = 0;
var t = function () { inputs[i % inputs.length].checked = true; i++; };
t(); setInterval(t, 500);
});import { useState } from "react";
import type { CSSProperties } from "react";
import styles from "./RadioFill.module.scss";
export type RadioFillOption = { value: string; label: string };
export type RadioFillProps = {
legend?: string;
options?: RadioFillOption[];
duration?: number;
easing?: string;
color?: string;
};
type Vars = CSSProperties & { "--duration"?: string; "--easing"?: string; "--color"?: string };
export default function RadioFill({
legend = "Payment method",
options = [
{ value: "card", label: "Card" },
{ value: "bank", label: "Bank transfer" },
{ value: "phone", label: "Phone" },
],
duration = 220,
easing = "ease-out",
color = "#fff7e6",
}: RadioFillProps) {
const [value, setValue] = useState(options[0]?.value);
const vars: Vars = { "--duration": `${duration}ms`, "--easing": easing, "--color": color };
return (
<fieldset className={styles.group} style={vars}>
<legend className={styles.legend}>{legend}</legend>
{options.map((o) => (
<label className={styles.radio} key={o.value}>
<input
type="radio"
name="radio-fill"
className={styles.srInput}
checked={value === o.value}
onChange={() => setValue(o.value)}
/>
<span className={styles.dot} aria-hidden="true" />
<span>{o.label}</span>
</label>
))}
</fieldset>
);
}03 Radio fill animation — Measured area 0.258% · moving frames 14/23Original by GODRICH · SCSS and React ship in the zip · 9 CSS Checkbox Radio Animations — Copy-Paste
