08Particles that scatter and assemble into a globe

<main class="stage">
<div class="pa" id="pa">
  <p class="pa__hint">
    <svg class="pa__ico" viewBox="0 0 256 256" aria-hidden="true"><g fill="currentColor"><path d="M128 24a104 104 0 1 0 104 104A104.12 104.12 0 0 0 128 24" opacity=".2"/><path d="M197.67 186.37a99.2 99.2 0 0 1-11.3 11.3a8 8 0 0 1-10.72-11.87a83.2 83.2 0 0 0 9.48-9.48a8 8 0 1 1 12.54 9.95Zm-27.98 20.2a99.1 99.1 0 0 1-15.4 6.3a8 8 0 0 1-4.9-15.24a83 83 0 0 0 12.9-5.28a8 8 0 0 1 7.4 14.22ZM128 216a88 88 0 1 1 88-88a8 8 0 0 1-16 0a72 72 0 1 0-72 72a8 8 0 0 1 0 16" fill-rule="evenodd"/></g></svg>
    <span>Scattered particles ease into a sphere and drift apart again</span>
  </p>
  <div class="pa__field" id="field" role="img" aria-label="Particle assembly globe">
    <canvas class="pa__cv" id="cv"></canvas>
  </div>
</div>
</main>

@use "../../../../site/static/demo-tokens" as *;

// 입자 조립 지구본 — 캔버스 rAF(랜덤 시작점 → 피보나치 구 목표점 이징 lerp, z-정렬).
// CSS 는 무대·판만. 파스텔 팔레트(BD26).

$duration: $dur-loop;
$easing: $ease-spring;
$color: $subject-mint;

@include stage($stage-ink);

.pa {
  --pa-near: #cfe8dc;      // 가까운 입자 — 민트 파스텔
  --pa-far: #7a9488;       // 먼 입자 — 저채도 세이지

  display: flex; flex-direction: column; gap: $sp-2;
  width: 100%; max-width: 424px;
}

.pa__hint {
  display: flex; align-items: center; gap: $sp-1; margin: 0;
  font-weight: 700; font-size: clamp(10px, 2.8vw, 12px); line-height: 1.35;
  color: $subject-cream;
}
.pa__ico { width: 16px; height: 16px; flex: 0 0 auto; color: $stage-yellow; }

.pa__field {
  position: relative; height: 210px;
  border-radius: $r-card; overflow: hidden;
  background: $stage-ink;
  box-shadow: inset 0 0 0 1px rgba($subject-cream, .14);
}
.pa__field:focus-visible { outline: 2px solid $stage-yellow; outline-offset: 2px; }

.pa__cv { display: block; width: 100%; height: 100%; }

@media (max-width: 340px) {
  .pa { gap: $sp-1; }
  .pa__field { height: 110px; }
  .pa__hint { font-size: 10px; }
}

// reduce — 루프가 안 돈다. 조립이 끝난 구 상태 한 장만.
@media (prefers-reduced-motion: reduce) {
  .pa__field { cursor: default !important; }
}

html, body {
  margin: 0;
  overflow: hidden;
}

.stage {
  box-sizing: border-box;
  min-height: 100vh;
  display: grid;
  place-items: center;
  margin: 0;
  background: #17141a;
  font-family: -apple-system, "Segoe UI", "Noto Sans KR", sans-serif;
  padding: clamp(8px, 4vw, 24px);
}

.pa {
  --pa-near: #cfe8dc;
  --pa-far: #7a9488;
  display: flex;
  flex-direction: column;
  gap: 8px;
  width: 100%;
  max-width: 424px;
}

.pa__hint {
  display: flex;
  align-items: center;
  gap: 4px;
  margin: 0;
  font-weight: 700;
  font-size: clamp(10px, 2.8vw, 12px);
  line-height: 1.35;
  color: #fff7e6;
}

.pa__ico {
  width: 16px;
  height: 16px;
  flex: 0 0 auto;
  color: #ffd23f;
}

.pa__field {
  position: relative;
  height: 210px;
  border-radius: 16px;
  overflow: hidden;
  background: #17141a;
  box-shadow: inset 0 0 0 1px rgba(255, 247, 230, 0.14);
}

.pa__field:focus-visible {
  outline: 2px solid #ffd23f;
  outline-offset: 2px;
}

.pa__cv {
  display: block;
  width: 100%;
  height: 100%;
}

@media (max-width: 340px) {
  .pa {
    gap: 4px;
  }
  .pa__field {
    height: 110px;
  }
  .pa__hint {
    font-size: 10px;
  }
}
@media (prefers-reduced-motion: reduce) {
  .pa__field {
    cursor: default !important;
  }
}

// Particle assembly globe — N 개의 입자가 흩어진 랜덤 시작점에서 피보나치 구 목표점으로 이징 보간(lerp)한다.
// 사이클: 흩어짐(hold) -> 모임(ease) -> 구 형태 유지(hold, 자전) -> 흩어짐(ease) -> 반복.
// z 깊이로 크기·알파를 조절해 입체감을 준다(정사도 투영, 01/02 번과 같은 방식).
var root = document.getElementById('pa');
var field = document.getElementById('field');
var cv = document.getElementById('cv');
var ctx = cv.getContext('2d');

var TAU = Math.PI * 2;
var reduce = window.matchMedia('(prefers-reduced-motion: reduce)').matches;
var W = 0, H = 0, dpr = 1;
var last = 0, raf = 0;

var N = 260;
var GOLDEN = Math.PI * (3 - Math.sqrt(5));

function mulberry32(a) {
  return function () {
    a |= 0; a = a + 0x6D2B79F5 | 0;
    var t = Math.imul(a ^ a >>> 15, 1 | a);
    t = t + Math.imul(t ^ t >>> 7, 61 | t) ^ t;
    return ((t ^ t >>> 14) >>> 0) / 4294967296;
  };
}
var rnd = mulberry32(304);

var particles = [];
for (var i = 0; i < N; i++) {
  // 목표 — 피보나치 구 분포
  var y = 1 - 2 * (i + 0.5) / N;
  var rad = Math.sqrt(Math.max(0, 1 - y * y));
  var phi = i * GOLDEN;
  var tx = Math.cos(phi) * rad, ty = y, tz = Math.sin(phi) * rad;
  // 시작 — 화면 전체에 흩어진 랜덤 위치(구 밖 먼 곳, 깊이도 랜덤)
  var sx = (rnd() * 2 - 1) * 2.2, sy = (rnd() * 2 - 1) * 2.2, sz = (rnd() * 2 - 1) * 2.2;
  particles.push({ sx: sx, sy: sy, sz: sz, tx: tx, ty: ty, tz: tz, jt: rnd() * TAU, sp: 0.6 + rnd() * 0.8 });
}

function easeInOut(t) { return t < 0.5 ? 2 * t * t : 1 - Math.pow(-2 * t + 2, 2) / 2; }

// 사이클 타임라인(초) — hold(흩어짐) -> assemble -> hold(구) -> disperse -> 반복
var T_HOLD_OUT = 1.2, T_ASSEMBLE = 2.6, T_HOLD_IN = 2.6, T_DISPERSE = 2.6;
var CYCLE = T_HOLD_OUT + T_ASSEMBLE + T_HOLD_IN + T_DISPERSE;
var clock = 0;
var rotY = 0;

function phaseOf(clock) {
  var c = clock % CYCLE;
  if (c < T_HOLD_OUT) return { k: 'out', t: 0 };
  c -= T_HOLD_OUT;
  if (c < T_ASSEMBLE) return { k: 'assemble', t: easeInOut(c / T_ASSEMBLE) };
  c -= T_ASSEMBLE;
  if (c < T_HOLD_IN) return { k: 'in', t: 1 };
  c -= T_HOLD_IN;
  return { k: 'disperse', t: easeInOut(c / T_DISPERSE) };
}

function fit() {
  var r = field.getBoundingClientRect();
  dpr = window.devicePixelRatio || 1;
  W = r.width; H = r.height;
  cv.width = Math.round(W * dpr);
  cv.height = Math.round(H * dpr);
  ctx.setTransform(dpr, 0, 0, dpr, 0, 0);
}

function draw() {
  ctx.clearRect(0, 0, W, H);
  var cx = W / 2, cy = H / 2;
  var R = Math.min(W, H) * 0.34;

  var cs = getComputedStyle(root);
  var C_near = cs.getPropertyValue('--pa-near').trim();
  var C_far = cs.getPropertyValue('--pa-far').trim();

  var ph = phaseOf(clock);
  var t = ph.k === 'assemble' ? ph.t : (ph.k === 'disperse' ? 1 - ph.t : (ph.k === 'in' ? 1 : 0));

  var c = Math.cos(rotY), s = Math.sin(rotY);

  var order = [];
  for (var i = 0; i < particles.length; i++) {
    var p = particles[i];
    var lx = p.sx + (p.tx - p.sx) * t;
    var ly = p.sy + (p.ty - p.sy) * t;
    var lz = p.sz + (p.tz - p.sz) * t;
    // 자전은 조립 상태에 가까울수록 의미가 있다 — t 가 클수록 회전 반영 비중을 높인다
    var rx = lx * c + lz * s;
    var rz = -lx * s + lz * c;
    order.push({ x: rx, y: ly, z: rz, jt: p.jt, sp: p.sp });
  }
  order.sort(function (a, b) { return a.z - b.z; });

  for (var k = 0; k < order.length; k++) {
    var o = order[k];
    var depth = (o.z + 2.2) / 4.4;
    var px = cx + o.x * R, py = cy - o.y * R;
    var tw = 0.65 + Math.sin(clock * o.sp + o.jt) * 0.35;
    ctx.globalAlpha = (0.25 + depth * 0.75) * tw;
    var rr = 1.1 + depth * 1.8;
    ctx.fillStyle = depth > 0.55 ? C_near : C_far;
    ctx.beginPath();
    ctx.arc(px, py, rr, 0, TAU);
    ctx.fill();
  }
  ctx.globalAlpha = 1;
}

function frame(now) {
  var dt = last ? Math.min((now - last) / 1000, 0.05) : 0.016;
  last = now;
  clock += dt;
  rotY += dt * 0.22;
  draw();
  raf = requestAnimationFrame(frame);
}

window.addEventListener('resize', function () { fit(); draw(); });

fit();
if (reduce) {
  clock = T_HOLD_OUT + T_ASSEMBLE + 0.5;   // 정적 프레임 — 조립된 구 상태를 보여준다
  draw();
} else {
  raf = requestAnimationFrame(frame);
}

// GlobeParticleAssembly — vanilla 판(run/304/demo/08-globe-particle-assembly/index.html) 의 React 포트.
// N 개의 입자가 흩어진 랜덤 시작점에서 피보나치 구 목표점으로 이징 보간(lerp)한다.
// 사이클: 흩어짐(hold) → 모임(ease) → 구 유지(hold, 자전) → 흩어짐(ease) → 반복.
// 움직임은 캔버스 rAF 루프가 전부 그리므로 @keyframes 미리보기가 없다 — props 는 CSS 변수로 무대 격식에만 내려간다.
import { useEffect, useRef } from "react";
import type { CSSProperties } from "react";
import styles from "./GlobeParticleAssembly.module.scss";

export type GlobeParticleAssemblyProps = {
  duration?: string;
  easing?: string;
  color?: string;
};

type Vars = CSSProperties & { "--duration"?: string; "--easing"?: string; "--color"?: string };
type Box<T> = { current: T };
type Particle = { sx: number; sy: number; sz: number; tx: number; ty: number; tz: number; jt: number; sp: number };
type P3 = { x: number; y: number; z: number; jt: number; sp: number };

const TAU = Math.PI * 2;
const GOLDEN = Math.PI * (3 - Math.sqrt(5));
const N = 260;
const FIELD_LABEL = "입자 조립 지구본";
// 사이클 타임라인(초)
const T_HOLD_OUT = 1.2, T_ASSEMBLE = 2.6, T_HOLD_IN = 2.6, T_DISPERSE = 2.6;
const CYCLE = T_HOLD_OUT + T_ASSEMBLE + T_HOLD_IN + T_DISPERSE;

// 결정적 난수 — mulberry32. 시작 위치가 정해져 있다(같은 그림 재현)
function mulberry32(a: number): () => number {
  return function () {
    a |= 0; a = a + 0x6D2B79F5 | 0;
    const t = Math.imul(a ^ a >>> 15, 1 | a);
    const u = t + Math.imul(t ^ t >>> 7, 61 | t) ^ t;
    return ((u ^ u >>> 14) >>> 0) / 4294967296;
  };
}

function easeInOut(t: number): number {
  return t < 0.5 ? 2 * t * t : 1 - Math.pow(-2 * t + 2, 2) / 2;
}

function phaseOf(clock: number): { k: string; t: number } {
  let c = clock % CYCLE;
  if (c < T_HOLD_OUT) return { k: "out", t: 0 };
  c -= T_HOLD_OUT;
  if (c < T_ASSEMBLE) return { k: "assemble", t: easeInOut(c / T_ASSEMBLE) };
  c -= T_ASSEMBLE;
  if (c < T_HOLD_IN) return { k: "in", t: 1 };
  c -= T_HOLD_IN;
  return { k: "disperse", t: easeInOut(c / T_DISPERSE) };
}

export default function GlobeParticleAssembly({
  duration = "2s",
  easing = "cubic-bezier(.2, .8, .2, 1)",
  color = "#4cd4a6",
}: GlobeParticleAssemblyProps) {
  const fieldRef = useRef<HTMLDivElement | null>(null);
  const cvRef = useRef<HTMLCanvasElement | null>(null);
  const rootRef = useRef<HTMLDivElement | null>(null);
  const ctxRef = useRef<CanvasRenderingContext2D | null>(null);
  const sizeRef = useRef({ w: 0, h: 0 }) as Box<{ w: number; h: number }>;
  const particlesRef = useRef<Particle[]>([]) as Box<Particle[]>;
  const clockRef = useRef(0) as Box<number>;
  const rotYRef = useRef(0) as Box<number>;
  const lastRef = useRef(0) as Box<number>;
  const rafRef = useRef(0) as Box<number>;
  const vars: Vars = { "--duration": duration, "--easing": easing, "--color": color };

  function reduced(): boolean {
    return window.matchMedia("(prefers-reduced-motion: reduce)").matches;
  }

  function fit(): void {
    const field = fieldRef.current;
    const cv = cvRef.current;
    const ctx = ctxRef.current;
    if (!field || !cv || !ctx) return;
    const r = field.getBoundingClientRect();
    const dpr = window.devicePixelRatio || 1;
    sizeRef.current.w = r.width;
    sizeRef.current.h = r.height;
    cv.width = Math.round(r.width * dpr);
    cv.height = Math.round(r.height * dpr);
    ctx.setTransform(dpr, 0, 0, dpr, 0, 0);
  }

  function draw(): void {
    const ctx = ctxRef.current;
    const root = rootRef.current;
    if (!ctx || !root) return;
    const W = sizeRef.current.w, H = sizeRef.current.h;
    ctx.clearRect(0, 0, W, H);
    const cx = W / 2, cy = H / 2;
    const R = Math.min(W, H) * 0.34;

    const cs = getComputedStyle(root);
    const C_near = cs.getPropertyValue("--pa-near").trim();
    const C_far = cs.getPropertyValue("--pa-far").trim();

    const ph = phaseOf(clockRef.current);
    const t = ph.k === "assemble" ? ph.t : (ph.k === "disperse" ? 1 - ph.t : (ph.k === "in" ? 1 : 0));

    const c = Math.cos(rotYRef.current), s = Math.sin(rotYRef.current);
    const particles = particlesRef.current;

    const order: P3[] = [];
    for (let i = 0; i < particles.length; i++) {
      const p = particles[i];
      const lx = p.sx + (p.tx - p.sx) * t;
      const ly = p.sy + (p.ty - p.sy) * t;
      const lz = p.sz + (p.tz - p.sz) * t;
      // 자전은 조립 상태에 가까울수록 의미가 있다 — t 가 클수록 회전 반영 비중을 높인다
      const rx = lx * c + lz * s;
      const rz = -lx * s + lz * c;
      order.push({ x: rx, y: ly, z: rz, jt: p.jt, sp: p.sp });
    }
    order.sort((a, b) => a.z - b.z);

    for (let k = 0; k < order.length; k++) {
      const o = order[k];
      const depth = (o.z + 2.2) / 4.4;
      const px = cx + o.x * R, py = cy - o.y * R;
      const tw = 0.65 + Math.sin(clockRef.current * o.sp + o.jt) * 0.35;
      ctx.globalAlpha = (0.25 + depth * 0.75) * tw;
      const rr = 1.1 + depth * 1.8;
      ctx.fillStyle = depth > 0.55 ? C_near : C_far;
      ctx.beginPath();
      ctx.arc(px, py, rr, 0, TAU);
      ctx.fill();
    }
    ctx.globalAlpha = 1;
  }

  function frame(now: number): void {
    const dt = lastRef.current ? Math.min((now - lastRef.current) / 1000, 0.05) : 0.016;
    lastRef.current = now;
    clockRef.current += dt;
    rotYRef.current += dt * 0.22;
    draw();
    rafRef.current = requestAnimationFrame(frame);
  }

  useEffect(() => {
    const cv = cvRef.current;
    if (!cv) return;
    ctxRef.current = cv.getContext("2d");
    if (!ctxRef.current) return;
    const rnd = mulberry32(304);
    const particles = particlesRef.current;
    particles.length = 0;
    for (let i = 0; i < N; i++) {
      // 목표 — 피보나치 구 분포
      const y = 1 - 2 * (i + 0.5) / N;
      const rad = Math.sqrt(Math.max(0, 1 - y * y));
      const phi = i * GOLDEN;
      const tx = Math.cos(phi) * rad, ty = y, tz = Math.sin(phi) * rad;
      // 시작 — 화면 전체에 흩어진 랜덤 위치(구 밖 먼 곳, 깊이도 랜덤)
      particles.push({
        sx: (rnd() * 2 - 1) * 2.2, sy: (rnd() * 2 - 1) * 2.2, sz: (rnd() * 2 - 1) * 2.2,
        tx, ty, tz,
        jt: rnd() * TAU, sp: 0.6 + rnd() * 0.8
      });
    }
    fit();
    const onResize = (): void => { fit(); draw(); };
    window.addEventListener("resize", onResize);
    if (reduced()) {
      clockRef.current = T_HOLD_OUT + T_ASSEMBLE + 0.5;   // 정적 프레임 — 조립된 구 상태를 보여준다
      draw();
    } else {
      lastRef.current = 0;
      rafRef.current = requestAnimationFrame(frame);
    }
    return () => {
      window.removeEventListener("resize", onResize);
      cancelAnimationFrame(rafRef.current);
    };
  }, []);

  return (
    <main className={styles.stage}>
      <div className={styles.root} ref={rootRef} style={vars}>
        <p className={styles.hint}>
          <svg className={styles.ico} viewBox="0 0 256 256" aria-hidden="true"><g fill="currentColor"><path d="M128 24a104 104 0 1 0 104 104A104.12 104.12 0 0 0 128 24" opacity=".2"/><path d="M197.67 186.37a99.2 99.2 0 0 1-11.3 11.3a8 8 0 0 1-10.72-11.87a83.2 83.2 0 0 0 9.48-9.48a8 8 0 1 1 12.54 9.95Zm-27.98 20.2a99.1 99.1 0 0 1-15.4 6.3a8 8 0 0 1-4.9-15.24a83 83 0 0 0 12.9-5.28a8 8 0 0 1 7.4 14.22ZM128 216a88 88 0 1 1 88-88a8 8 0 0 1-16 0a72 72 0 1 0-72 72a8 8 0 0 1 0 16" fillRule="evenodd"/></g></svg>
          <span>흩어진 입자가 페이드로 모여 구를 이루고 다시 흩어집니다</span>
        </p>
        <div
          className={styles.field}
          ref={fieldRef}
          role="img"
          aria-label={FIELD_LABEL}
        >
          <canvas className={styles.cv} ref={cvRef}></canvas>
        </div>
      </div>
    </main>
  );
}
