04Wheel delta — a stepper whose value changes by the amount and direction the wheel moves over it

<main class="stage">
<div class="nspwd is-demo" id="nspwd">
  <div class="nspwd__panel">
    <span class="nspwd__label">Zoom level</span>
    <span class="nspwd__value" id="nspwdValue">100%</span>
    <div class="nspwd__track">
      <span class="nspwd__fillDown" id="nspwdFillDown"></span>
      <span class="nspwd__mid"></span>
      <span class="nspwd__fillUp" id="nspwdFillUp"></span>
    </div>
    <span class="nspwd__hint">Once the wheel delta accumulates, it steps by one</span>
  </div>
</div>
</main>

@use "../../../../site/static/demo-tokens" as *;

// 계산 겹: 휠 delta 를 잔여값에 누적하다 문턱을 넘을 때만 한 칸 커밋하고, 남은 잔여값은
// 매 프레임 마찰(0.9배)로 감쇠시킨다 — 트랙 채움은 scaleX 로 그 잔여값을 실시간 표시한다.

$duration: $dur-instant;
$easing: $ease-out;
$color: $subject-blue-deep;

@include stage($stage-paper);

.stage { position: relative; }

.nspwd {
  width: min(220px, 68vw);
}

.nspwd__panel {
  display: flex;
  flex-direction: column;
  align-items: center;
  gap: $sp-3;
  padding: $sp-5;
  border-radius: $r-card;
  background: rgba($subject-ink, .05);
}

.nspwd__label {
  color: rgba($subject-ink, .72);
  font-weight: 700;
  font-size: 12px;
}

.nspwd__value {
  color: $subject-ink;
  font-weight: 700;
  font-size: 28px;
  font-variant-numeric: tabular-nums;
}

.nspwd__track {
  position: relative;
  width: 100%;
  height: $sp-2;
  border-radius: $r-xs;
  background: rgba($subject-ink, .12);
  display: flex;
  overflow: hidden;
}

.nspwd__fillDown,
.nspwd__fillUp {
  display: block;
  width: 50%;
  height: 100%;
  background: $color;
  transform: scaleX(0);
}

.nspwd__fillDown { transform-origin: right center; }
.nspwd__fillUp { transform-origin: left center; }

.nspwd__mid {
  position: absolute;
  left: 50%;
  top: -3px;
  bottom: -3px;
  width: 2px;
  background: $subject-ink;
  opacity: .3;
}

.nspwd__hint {
  color: rgba($subject-ink, .72);
  font-size: 11px;
  text-align: center;
}

@media (max-width: 340px) {
  .nspwd__panel { padding: $sp-4; gap: $sp-2; }
  .nspwd__value { font-size: 24px; }
}

@media (prefers-reduced-motion: reduce) {
  .nspwd__fillUp, .nspwd__fillDown { transition: none !important; }
}

html, body {
  margin: 0;
  overflow: hidden;
}

.stage {
  box-sizing: border-box;
  min-height: 100vh;
  display: grid;
  place-items: center;
  margin: 0;
  background: #ffffff;
  font-family: -apple-system, "Segoe UI", "Noto Sans KR", sans-serif;
  padding: clamp(8px, 4vw, 24px);
}

.stage {
  position: relative;
}

.nspwd {
  width: min(220px, 68vw);
}

.nspwd__panel {
  display: flex;
  flex-direction: column;
  align-items: center;
  gap: 12px;
  padding: 20px;
  border-radius: 16px;
  background: rgba(23, 20, 26, 0.05);
}

.nspwd__label {
  color: rgba(23, 20, 26, 0.72);
  font-weight: 700;
  font-size: 12px;
}

.nspwd__value {
  color: #17141a;
  font-weight: 700;
  font-size: 28px;
  font-variant-numeric: tabular-nums;
}

.nspwd__track {
  position: relative;
  width: 100%;
  height: 8px;
  border-radius: 4px;
  background: rgba(23, 20, 26, 0.12);
  display: flex;
  overflow: hidden;
}

.nspwd__fillDown,
.nspwd__fillUp {
  display: block;
  width: 50%;
  height: 100%;
  background: #0a4fe8;
  transform: scaleX(0);
}

.nspwd__fillDown {
  transform-origin: right center;
}

.nspwd__fillUp {
  transform-origin: left center;
}

.nspwd__mid {
  position: absolute;
  left: 50%;
  top: -3px;
  bottom: -3px;
  width: 2px;
  background: #17141a;
  opacity: 0.3;
}

.nspwd__hint {
  color: rgba(23, 20, 26, 0.72);
  font-size: 11px;
  text-align: center;
}

@media (max-width: 340px) {
  .nspwd__panel {
    padding: 16px;
    gap: 8px;
  }
  .nspwd__value {
    font-size: 24px;
  }
}
@media (prefers-reduced-motion: reduce) {
  .nspwd__fillUp, .nspwd__fillDown {
    transition: none !important;
  }
}

(function () {
  var root = document.getElementById('nspwd');
  var panel = root.querySelector('.nspwd__panel');
  var valueEl = document.getElementById('nspwdValue');
  var fillUp = document.getElementById('nspwdFillUp');
  var fillDown = document.getElementById('nspwdFillDown');

  var MIN = 50, MAX = 200, STEP = 10, THRESH = 60;
  var value = 100;
  var residual = 0;

  function render() { valueEl.textContent = value + '%'; }
  function paintTrack() {
    var p = Math.min(1, Math.abs(residual) / THRESH);
    fillUp.style.transform = 'scaleX(' + (residual > 0 ? p : 0).toFixed(3) + ')';
    fillDown.style.transform = 'scaleX(' + (residual < 0 ? p : 0).toFixed(3) + ')';
  }

  // 계산 겹: 휠 delta 를 잔여값(residual)에 누적하다가 문턱(THRESH)을 넘을 때만 한 칸 커밋한다.
  // 커밋되지 않은 잔여값은 매 프레임 마찰(0.9배)로 감쇠시켜 손을 놓아도 서서히 0으로 가라앉는다.
  function applyDelta(dy) {
    residual += dy;
    while (residual >= THRESH) {
      value = Math.min(MAX, value + STEP);
      residual -= THRESH;
      render();
    }
    while (residual <= -THRESH) {
      value = Math.max(MIN, value - STEP);
      residual += THRESH;
      render();
    }
    paintTrack();
  }

  function decayFrame() {
    if (Math.abs(residual) > 0.5) {
      residual *= 0.90;
      paintTrack();
    } else if (residual !== 0) {
      residual = 0;
      paintTrack();
    }
    requestAnimationFrame(decayFrame);
  }
  requestAnimationFrame(decayFrame);

  panel.addEventListener('wheel', function (e) {
    root.classList.remove('is-demo'); stopAutoplay();
    e.preventDefault();
    applyDelta(e.deltaY);
  }, { passive: false });

  var seq = [16, 16, 16, 16, -16, -16, -16, -16];
  var idx = 0;
  var autoplayTimer = null;
  function stopAutoplay() { if (autoplayTimer) { clearInterval(autoplayTimer); autoplayTimer = null; } }
  var reduce = window.matchMedia('(prefers-reduced-motion: reduce)').matches;
  if (!reduce) {
    autoplayTimer = setInterval(function () {
      applyDelta(seq[idx % seq.length]);
      idx += 1;
    }, 180);
  }
  render();
})();

import { useEffect, useRef } from "react";
import styles from "./NumberStepperScrollWheelDelta.module.scss";

export type NumberStepperScrollWheelDeltaProps = {
  color?: string;
};

export default function NumberStepperScrollWheelDelta({
  color = "#0a4fe8",
}: NumberStepperScrollWheelDeltaProps) {
  const rootRef = useRef<HTMLDivElement | null>(null);

  useEffect(() => {
    const root = rootRef.current;
    if (!root) return;
    const panel = root.querySelector<HTMLDivElement>(`.${styles.panel}`);
    const valueEl = root.querySelector<HTMLSpanElement>(`.${styles.value}`);
    const fillUp = root.querySelector<HTMLSpanElement>(`.${styles.fillUp}`);
    const fillDown = root.querySelector<HTMLSpanElement>(`.${styles.fillDown}`);
    if (!panel || !valueEl || !fillUp || !fillDown) return;

    const MIN = 50, MAX = 200, STEP = 10, THRESH = 60;
    let value = 100;
    let residual = 0;
    let rafId: number | null = null;

    function render() { valueEl!.textContent = value + "%"; }
    function paintTrack() {
      const p = Math.min(1, Math.abs(residual) / THRESH);
      fillUp!.style.transform = "scaleX(" + (residual > 0 ? p : 0).toFixed(3) + ")";
      fillDown!.style.transform = "scaleX(" + (residual < 0 ? p : 0).toFixed(3) + ")";
    }

    // 계산 겹: 휠 delta 를 잔여값(residual)에 누적하다가 문턱(THRESH)을 넘을 때만 한 칸 커밋한다.
    // 커밋되지 않은 잔여값은 매 프레임 마찰(0.9배)로 감쇠시켜 손을 놓아도 서서히 0으로 가라앉는다.
    function applyDelta(dy: number) {
      residual += dy;
      while (residual >= THRESH) {
        value = Math.min(MAX, value + STEP);
        residual -= THRESH;
        render();
      }
      while (residual <= -THRESH) {
        value = Math.max(MIN, value - STEP);
        residual += THRESH;
        render();
      }
      paintTrack();
    }

    function decayFrame() {
      if (Math.abs(residual) > 0.5) {
        residual *= 0.90;
        paintTrack();
      } else if (residual !== 0) {
        residual = 0;
        paintTrack();
      }
      rafId = requestAnimationFrame(decayFrame);
    }
    rafId = requestAnimationFrame(decayFrame);

    const onWheel = (e: WheelEvent) => {
      root!.classList.remove(styles.isDemo);
      stopAutoplay();
      e.preventDefault();
      applyDelta(e.deltaY);
    };
    panel.addEventListener("wheel", onWheel, { passive: false });

    const seq = [16, 16, 16, 16, -16, -16, -16, -16];
    let idx = 0;
    let autoplayTimer: ReturnType<typeof setInterval> | null = null;
    function stopAutoplay() {
      if (autoplayTimer) { clearInterval(autoplayTimer); autoplayTimer = null; }
    }
    const reduce = window.matchMedia("(prefers-reduced-motion: reduce)").matches;
    if (!reduce) {
      autoplayTimer = setInterval(() => {
        applyDelta(seq[idx % seq.length]);
        idx += 1;
      }, 180);
    }
    render();

    return () => {
      stopAutoplay();
      if (rafId) cancelAnimationFrame(rafId);
      panel!.removeEventListener("wheel", onWheel);
    };
  }, []);

  return (
    <div ref={rootRef} className={`${styles.stage} ${styles.isDemo}`} style={{ ["--color" as string]: color }}>
      <div className={styles.panel}>
        <span className={styles.label}>확대 배율</span>
        <span className={styles.value}>100%</span>
        <div className={styles.track}>
          <span className={styles.fillDown} />
          <span className={styles.mid} />
          <span className={styles.fillUp} />
        </div>
        <span className={styles.hint}>휠 델타가 쌓이면 한 칸씩 바뀝니다</span>
      </div>
    </div>
  );
}
